Carbon fabric Twill 200 g/m2

  • Carbon fabric Twill 200 g/m2
  • Carbon fabric Twill 200 g/m2

  • Article code: S10740

Carbon Twill weave is mainly used for its high stiffness, especially in motorsport, aircraft construction and yacht building.

€ 39,95
€ 33,02 Excl. tax

Add to wishlist

Buy now Pay in 14 days with Klarna

  • Fast shipping! Everything available from stock
  • Buy from the specialist
  • Extended internal Laboratory
  • More than half a million satisfied customers
Placeholder4.82

Uitstekend

Product description

Carbon fabric Twill 200 g/m2

Carbon twill weave 200 g/m2

Carbon fabrics are known for their very high tensile strength and low weight.

Carbon fabrics, are very flexible and therefore easy to process in shapes with curves, difficult contours and details.

This carbon fabric is often used as a reinforcing fabric. Due to the well-known appearance, this special fabric is also in demand from a design point of view and is therefore also used as an overlay / finishing layer.

We advise to use this product with epoxy for functional applications. This is because epoxy is flexible and therefore moves better with the flexible carbon than other resins do. This increases the impact resistance of the product. Polyester is also possible, but especially for decorative use.

We recommend using vacuum assistet hand lay-up for high-end application. This means using a vacuum bag around the item to let the resin penetrate the pores of the fabric under vacuum. Simple lamination without vacuum is also possible.

ProductDensityWidthThicknessWeaveProcesResinResin usage
Carbon fibre cloth Twill 200 PrimeTex 43200 UE S200 g/m21250 mm0,2 mmTwill 2/2Laminating, vacuum lay-upEpoxy390g/m2

Specifications

Specifications for: Carbon fabric Twill 200 g/m2

  • Material Carbon fibre woven fabric
  • Density g/m² 200
  • Weave Twill 2/2
  • Thickness 0,2 mm
  • Width 1,27 m
  • View all specifications
  • Resin Polyester and epoxy
  • Process Hand lay-up, vacuum hand lay-up
  • Resin usage 390g/m2
