Polyurethane Casting Resin D70 Quick Set

  • Polyurethane Casting Resin D70 Quick Set
  • Polyurethane Casting Resin D70 Quick Set
  • Polyurethane Casting Resin D70 Quick Set
  • Polyurethane Casting Resin D70 Quick Set

In stock

  • Article code: S10174

✔ Hard, Small Castings
✔ Beige, Strong, High details
✔ Shore D 70 Unfilled
✔ Castings 4mm <> 30mm
✔ 2 minutes working time
✔ Mixing ratio (Weight) 100: 100

€ 14,95
€ 12,36 Excl. tax

Add to wishlist

  • Fast shipping! Everything available from stock
  • Buy from the specialist
  • Shipping Worldwide
  • Not good? Money Back!
Placeholder4.85

Ratings

Product description

Polyurethane Casting Resin D70 Quick Set

  • White colored two or three-piece system
  • Designed for fast, accurate castings
  • Can be molded into a layer thickness of 40 mm, provided that you are using sufficient filler
  • Filler quantity varies depending on application, and even entirely omittable
  • After 40 minutes, ontmalbaar (in mixture 1: 1: 3)
  • Can be used with up to 600% (of the total weight) are mixed with filler

Description

This PU results in a hard plastic that is very suitable for small castings, fixing molds, foundry models, replicas and prototypes.

A polyurethane casting system consisting of an A- and B-component. Optional fillers can be added. This casting system is characterized in particular by its fast de-mould time and ease of use. The system can be used perfectly for small castings, fixing molds, foundry models, replicas and prototypes.

Technical data

Technische Daten

Ohne Füllstoff

  • Mischungsverhältnis: A: B = 1: 1
  • Bearbeitungszeit: 2 Minuten
  • Entformzeit bei 20 ° C: 15 Minuten
  • Dichte: 1,08 g / cm³
  • Lineare Schrumpfung: 0,2%
  • Maximale Dicke pro Guss: 4-30 mm.
  • Glastemperatur: 60-70 ° C.
  • Härte: Shore D 70

Mit Füllstoff

  • Mischungsverhältnis: A: B: Füllstoff = 1: 1: 3
  • Bearbeitungszeit: 4 Minuten
  • Entformzeit bei 20 ° C: 30-40 Minuten
  • Dichte 1,6 g / cm³
  • Lineare Schrumpfung: 0,15%
  • Maximale Dicke pro Guss: 30-40 mm.
  • Glastemperatur: 60-70 ° C.
  • Härte: Shore D 80

Processing

Pour the components together and mix well. Pour the mixed product with a constant flow into the mold, making sure no air is entrapped. Excessive heat in castings of more than 30 mm thickness can be prevented by pouring multiple successive layers (let the layer harden till it is over its exothermal peak before the next layer is poured). Hold the de-moulding until the specified time has elapsed. The thermal and mechanical properties will develop rapidly, but it is possible to improve the thermal behavior by "post curing" the cast for a few hours at a temperature of 60°C.

Important

The dehumidifiers in these products tend to settle out. We therefore recommend aggitating the components before decanting. The less filler you add, the higher the exothermic peak will be. Adding a heat conducting filler will make casting thicker layers possible. Use a mixing vessel with large surface area in order to make a maximum pot life. Adding to much filler might make the product more rigid and brittle.

Durability

The polyurethane casting system should be stored in a dry place between 6-28°C, the expiration date, which is based on storage within the specified conditions, is indicated on the packaging. Opened packages should be processed as quickly as possible to ensure product quality. Max shelf life is 6 months

safety

The products are generally quite safe in use as long as one takes the usual precautions which is common in processing of chemical products. For example, the two components must not come into contact with food or eating utensils. Contact with the skin of one or both components must be avoided. If after cleaning skin stays sensitive contact a docter. Rinse eyes well for 15 minutes in case material gets in the eyes and contact docter. Do not ingest. For further information see Safety Data Sheet.

Further important safety information

H-Code hazard statements

H319 Causes serious eye irritation.

H332 Harmful by inhalation.

H315 Causes skin irritation.

H319 Causes serious eye irritation.

H334 May cause allergy or asthma symptoms or breathing difficulties if inhaled.

H317 May cause an allergic skin reaction.

H351 Suspected of causing cancer.

H335 May cause respiratory irritation.

H411 ​​Toxic to aquatic life with long lasting effects H373 May cause damage to the lungs and the respiratory tract through prolonged or repeated exposure.

EUH204 Contains isocyanates. May produce an allergic reaction.

P-Code precautions

P260 Do not breathe dust / fume / gas / mist / vapor / spray.

P264 Wash thoroughly after handling.

P273 Avoid release to the environment.

P280 Wear protective gloves / protective clothing / eye protection /
face protection / hearing protection.

P284 [In case of inadequate ventilation] wear respiratory protection.

P305 + P351 + P338 IF IN EYES: Rinse cautiously with water for several times
minutes; remove contact lenses, if possible; keep rinsing.

P337 + P313 If eye irritation persists: Get medical advice / attention.

P405 Store locked up.

P501 Dispose of contents and container in accordance with local / regional / national /
international regulations.

Documentation

Product information sheet Polyurethane Casting Resin D70 Quick Set

Tutorial Filled PU:

Specifications

Specifications for: Polyurethane Casting Resin D70 Quick Set

  • Color A Comp. Grey / White
  • Color B Comp. Blue
  • end Color White
  • cured density 1,08 g/cm3 / 1,60 g/cm3
  • viscosity mixture 1300 cPS
  • View all specifications
  • Mixing ratio A/ B 25:100
  • Shore (D) 70-80
  • Working Time 2 Minutes / 4 Minutes
  • Curing time 15 Minutes / 30-40 Minutes
  • Linear shrinkage 0,2% / 0,15%
  • Advised coating thickness 4-30 mm / 30-40 mm
