Silicone Addition Clear 5 (very soft)

  • Silicone Addition Clear 5 (very soft)

In stock

  • Article code: S10045

✔ Flexible, Crystal clear
✔ Suitable for potting
✔ Shore (A) 5 (Very Soft)
✔ Low shrinkage (<0.1%)
✔ 30 minutes working time
✔ Mixing ratio (Weight) 100: 100

€ 66,50
€ 54,96 Excl. taxFree shipping

Add to wishlist

Buy now Pay in 14 days with Klarna

  • Fast shipping! Everything available from stock
  • Buy from the specialist
  • Shipping Worldwide
  • Not good? Money Back!


Product description

Silicone Addition Clear 5 (very soft)

Crystal clear silicones that are suitable for flexible casting of LEDs and optical elements, but also for modeling for simulating water or windows.

The Silicones Addition Crystal clear 5 is a 2-component (Platinum) addition curing silicone which cures at room temperature. The silicones are, after mixing, very liquid and crystal clear.

Because of the low shrinkage and very good clarity these silicones are ideal for potting of electronics, optical elements or as a mold for models without undercuts that need to be cut out. The silicone is not suited for normal molds because of the low tear strength.

  • Low shrinkage of <0.1%.
  • Very liquid so self-deaerating
  • Crystal clear
  • Shore A 5 very soft
  • Suitable for potting

Technical data

  • Mixing ratio in weight: A:B = 100:100
  • Pot life at 20°C: 30 minutes
  • De-mould time at 20°C: 2 hours
  • Viscosity at 20°C: 4000 MPa's
  • Color: transparant clear
  • Hardness: Shore A 4~6

Note: Pot life / de-mould time is highly dependent on temperature! At a higher temperature, the processing time and de-mould time are shorter.


The Silicone A and B component can easily be mixed by hand or by machine. Mix the A and B component carefully and in the indicated ratio (100 parts A and 100 parts B by weight). Process the mixture within the pot life and demould only after it is cured complete. Alternatively, you can speed up the curing process by placing the whole mould in an oven. Please note that air bubbles will then have less time to escape the casting.

Extra information

Trapping of air bubbles can be prevented best by placing the silicone under vacuum immediately after mixing. To prevent air bubbles, stir the A and B component well but slowly without stirring in air. We advise to use a figur of 8 motion. If you want to reduce the Shore (hardness), you can add silicone oil from the shop. Please note that oil does not bind to the silicone network and may over time bleed from the silicone.

If you do not want to pour the silicone spatula but you can add Silicone Thixo A (note: not Silicone Thixo C !!). You can also add Fumed Silica. You can color these silicones intensely by using silicon dye.

The silicon might obtain a very slight yellow hue when used at elevated temperatures (>80°C).

Please note: This is an addition curing silicone. This type of silicones may experience cure inhibition when coming into contact with sulfer, nitrogen, amino groups and metl salts. If you are not certain that the products you use (including gloves, spatulas and cups) contain these ingredients, please do a little test first! These components are often found in many latex gloves, some platicines, glues, laquers, condensation curing silicones, silicone caulk, natural rubbers and 3D printing materials (mainly stereolithography). If you still want to use such materials you might have to brush on a protective layer of poly vinyl alcohol.


Provided that the silicone in sealed packaging, stored cool and frost-free, the shelf life is at least one year.


If you use silicone frequently we advice the use of gloves and to work in a properly ventilated area. For safety information see the safety data sheet.

Product Information Silicone Addition Clear 5

EN- Safety data sheet Nedsil Clear 5 A component

EN- Safety data sheet Nedsil Clear 5 B component


Specifications for: Silicone Addition Clear 5 (very soft)

  • Shore (A) 4~6
  • Color A Comp. Clear
  • Color B Comp. Clear
  • end Color Clear
  • cured density 1,03 g/cm3
  • View all specifications
  • viscosity mixture 4000 mPa.s
  • Mixing ratio A/ B 100:100
  • Working Time 30 minutes
  • Curing time 2 hours
  • tensile strength 2 N/mm2
  • extensibility 200%
  • tear Strength > 6 N/mm
  • Linear shrinkage<0,1%
